12,000 BTU 19.4 SEER Ceiling Recess Heat Pump System. LG's Four-Way Ceiling Cassette systems, such as this LC127HV4, have several advantages over wall mounted systems. By recessing the LCN127HV4 indoor unit, a 7/8" thick grille is the only part of the equipment that stays visible. Unobtrusive comfort isn't the only advantage of a ceiling cassette; with four air flow directions, the LC127HV4 provides excellent coverage for consistent levels of comfort. . If you're looking for a low-profile alternative to wall mounted ductless heat pump systems, LG's Four-Way Ceiling Cassettes are a great choice.
TECH SPECS
General Information | |
|---|
| Type | Ceiling Cassette |
| Product Line | Multi F |
| Product Sub-line | Four-Way Ceiling Cassette |
| Operating Mode | Heating and Cooling |
| Indoor Unit Size(s) | 12 |
| Multi-Zone Compatible | Yes |
| Refrigerant Type | R-410A |
| Installation Location | Indoor |
| Grille | Included |
| Required Grille Model | PT-UQC |
Performance | |
|---|
| Cooling BTU | 12000 |
| Cooling Capacity | 12000 BTU |
| Minimum Air Flow | 247CFM |
| Maximum Air Flow | 335 CFM |
| Maximum Sound Level | 38 dB |
| Minimum Sound Level | 32 dB |
Electrical Data | |
|---|
| Phase | 1 |
| Frequency | 60 Hz |
Dimensions | |
|---|
| Liquid Connection Size | 1/4 Inch |
| Gas Connection Size | 3/8 Inch |
| Product Height | 8 7/16 Inches |
| Product Width | 22 7/16 Inches |
| Product Depth | 22 7/16 Inches |
| Product Weight | 31 Pounds |
| Shipping Weight | 40 Pounds |
Certifications | |
|---|
| ETL Listed | Yes |
| AHRI Certified | Yes |
| UL Listed | Yes |
| ISO Certified | Yes |
Warranty Information | |
|---|
| Parts Warranty | 5 Years |
WARRANTY INFORMATION
The Standard Warranty Period and the Compressor Warranty Period are extended to a total of ten (10) years (the “Extended Warranty Period”) for qualified Systems that have been (a) installed by a party that has completed the Training Requirements, (b) installation is pursuant to LG’s published instructions, and (c) product is registered within 60 days of startup at https://lg-dfs-warranty.com/
